Compact Open Frame Scale Bases ENQUIRE NOW BUY NOW

WSSPB

Features
Specifications
Downloads
  • legal for trade use (TS2118 & TS2373)
  • trade approval applies when connected to an approved indicator
  • constructed from high quality stainless steel
  • IP67 rated load cell
  • open frame design
  • choice of platform sizes and capacities to suit individual requirements
  • suitable for a wide range of applications including harsh and wet environments
  • includes sturdy stainless steel pole for mounting scale indicator



OPTIONS

  • roller frame complete with eight rollers - compatible with 60 kg and 150 kg models. PVC rollers order code WSSPB4050ROLLERS or Stainless Steel rollers order code WSSPB4050SSROLL. Depicted in image gallery.
Legal for Trade Use

Yes when connected to an approved indicator

TS2118 & TS2373

Capacity Choices Please select preferred option from Variations
Base Shape Rectangular
Base Material Stainless steel
Base Cover Material Stainless steel
Frame Design Open frame
Platter Lift Mechanism Not available
Loading Ramps Not available
Environment Suitability Dry, Wet, Harsh
Ingress Protection Rating IP67



Maximum Approved Divisions per range:

  • WSSPB30246K = 4000 d/range
  • WSSPB30215K = 4000 d/range
  • WSSPB323615K = 4000 d/range
  • WSSPB323630K = 3000 d/range
  • WSSPB405060K = 3000
  • WSSPB4050150K = 3000







Compact Open Frame Scale Bases ENQUIRE NOW BUY NOW

WSSPB

Our fully Stainless Steel Scale Bases are trade approved in New Zealand when connected to an appropriate scale indicator and come in a choice of platform sizes and capacities to suit your individual requirements. Engineered with IP67 rated stainless steel loads cells, these scale bases are well suited to harsh and wet environments.

The 60 kg and 150 kg models are available with an optional roller frame complete with 8 rollers in a choice of pvc or stainless steel. Adding the roller frame to your WSSPB Base reduces the amount of physical effort required when moving product from conveyor belt to scale and off again.

FEATURES AND SPECIFICATIONS

Price of Selection (NZ$ excl GST)

POA

Variations

WSSPB30246K

Platform Size (mm): 300 (W) x 240 (D) x 110 (H)
Maximum Capacity: 6 kg
Graduation Interval: 1 g / 2 g

POA

WSSPB302415K

Platform Size (mm): 300 (W) x 240 (D) x 110 (H)
Maximum Capacity: 15 kg
Graduation Interval: 2 g / 5 g

POA

WSSPB323615K

Platform Size (mm): 320 (W) x 360 (D) x 110 (H)
Maximum Capacity: 15 kg
Graduation Interval: 2 g / 5 g

POA

WSSPB323630K

Platform Size (mm): 320 (W) x 360 (D) x 110 (H)
Maximum Capacity: 30 kg
Graduation Interval: 5 g / 10 g

POA

WSSPB405060K

Platform Size (mm): 400 (W) x 500 (D) x 120 (H)
Maximum Capacity: 60 kg
Graduation Interval: 20 g

POA

WSSPB4050150K

Platform Size (mm): 400 (W) x 500 (D) x 120 (H)
Maximum Capacity: 150 kg
Graduation Interval: 50 g

POA

Spare Parts / Options

Frame With Rollers for WSSPB4050 Scale Bases

WSSPB4050ROLLERS

POA
